Process Visualization (Level 3)

Learn HMI / SCADA hands-on by developing your own live interfaces for a running system.

Process Visualization (Level 3)
Process Visualization (Level 3)

Process Visualization (Level 3) udemy course

Learn HMI / SCADA hands-on by developing your own live interfaces for a running system.

What you'll learn:

  • By the end of this course, you will have created HMI / SCADA interfaces using various technologies allowing operators to interact with a live, running system.
  • Using the provided PLC program as the basis for our interfaces, you'll be creating graphical interfaces to run the process and log data into a SQL database.
  • You'll know how to map data between RSLogix 500 projects and several visualization technologies.
  • You'll have some AMAZING demo projects to show off in interviews.


  • You will need to download a VERY LARGE archive in order to take full advantage of this course. That file is OVER 10gb! The alternative is to download a LOT of software individually and install and configure it all bit by bit. While I DO provide guidance for doing that in the course, I CANNOT provide one-on-one support.
  • All software required for this course (except for VMWare if you use a Mac) will be provided. That being said, the versions provided are unregistered, not activated and running in demo mode. Continued use of these programs requires purchase, activation and licensure, however all of it will work for a limited time (adequate to complete this course). So you won't have to pay for software to learn, but the software WILL eventually stop working at the end of the various trial periods.
  • The only software you need to worry about being able to run is VMWare. If you have a Windows PC, you can download VMWare Player for free. If you have a Mac, you will need to purchase a copy of VMWare Workstation... or use a Windows computer.
  • Familiarity with RSLogix 500, RSLinx and RSLogix 500 Emulate is required for this course.


As a PLC programmer, there are two sides of the coin that you MUST know to get the job done, and those are the PLC and the HMI.  In my first two PLC courses (only ten dollars each on PLC Dojo), you learned the ins and outs of PLC and have already created some pretty complex programs to run machines.

But if people aren't able to interact with those machines, they aren't going to be of much use!  In this course, you're going to learn about HMI and SCADA by creating graphical interfaces operators will use to monitor automated process, establish operating parameters, and even acquire and warehouse data from a running system. Process Visualization (Level 3) Udemy

There are multiple solutions on the market to accomplish these tasks, and as such, we're going to be covering several.  Wonderware (Schneider Electric / Indusoft) is perhaps the top solution in the world of process visualization.  As such, we'll be working extensively with that technology, but we won't limit ourselves to a single package.

We'll also be working hands-on with InduSoft, EasyBuilder 5000 and AdvancedHMI, and hands-off with FactoryTalk View Studio and C-More so by the end of this course, you're going to actually know and have working experience with most of what people are using in the world of automation today.

What's covered in each of the five PLC courses I teach here and on my own PLC Dojo site?

PLC Fundamentals (Level 1) teaches you how to program with the focus on ladder logic, which is the most popular PLC programming language.  The goal is to teach you everything you need to know to make a PLC do what you want it to do.  You are also given all the software necessary to both CREATE and RUN your own programs live - right on your own computer.

Applied Logic (Level 2) forces you to take what you've learned and solve problem after progressively harder problem unassisted.  You get a spec and are told simply: "Make it work, and don't progress until you have."  After, you get to watch me solve each one as well.  By the end, you don't just know how to program - you are a PROGRAMMER.

Process Visualization (Level 3) gives you both knowledge and experience in FIVE different HMI / SCADA development environments.  By the end, you've created several COMPLETE visualization (screen) projects that you can actually run on your own computer (and SHOW PEOPLE in an interview) with no additional hardware.

IEC Paradigms (Level 4) is only for the heavyweights.  This course teaches you how to program using all five IEC programming languages (plus one more) in multiple environments.  There are projects as well, so by the end, you have seen it all and DONE it all as well.  There won't be anything anybody can show you that you won't already be familiar with.

TIA Portal Master Project (Level 5) is the culmination of everything. In that course, you'll program an entire power plant using all five PLC programming languages (in PARALLEL!) with a full HMI. It's a massive and complex project that really showcases your talents in an interview!

Who this course is for:

Course Details:

  • 16.5 hours on-demand video
  • 16 articles
  • 22 downloadable resources
  • Full lifetime access
  • Access on mobile and TV
  • Certificate of completion

Process Visualization (Level 3) udemy free download

Learn HMI / SCADA hands-on by developing your own live interfaces for a running system.

Demo Link:
